Diodes Incorporated RS1MB-13-F Alternative Datasheet
Part Number: FSM17PL-TP-HF
Manufacturer: Micro Commercial Co
Description: Diode 1000 V 1A Surface Mount SOD-123FL
Datasheet: FSM17PL-TP-HFDatasheet
Features:
• For Surface Mount Application
• Fast Recovery Time For High Efficiency
• Glass Passivated Junction
• Epoxy Meets UL 94 V-0 Flammability Rating
• Halogen Free. “Green” Device
• Moisture Sensitivity Level 1
• Lead Free Finish/RoHS Compliant
Product Attributes:
|
Part Number
|
FSM17PL-TP-HF
|
|
|
Manufacturer
|
Micro Commercial Co
|
Diodes Incorporated
|
|
Part Status
|
Active
|
Active
|
|
Voltage - DC Reverse (Vr) (Max)
|
1000 V
|
1000 V
|
|
Current - Average Rectified (Io)
|
1A
|
1A
|
|
Voltage - Forward (Vf) (Max) @ If
|
1.3 V @ 1 A
|
1.3 V @ 1 A
|
|
Speed
|
Fast Recovery =< 500ns, > 200mA (Io)
|
Fast Recovery =<
500ns, > 200mA (Io)
|
|
Reverse Recovery Time (trr)
|
500 ns
|
500 ns
|
|
Current - Reverse Leakage @ Vr
|
5 µA @ 1000 V
|
5 µA @ 1000 V
|
|
Capacitance @ Vr, F
|
15pF @ 4V, 1MHz
|
15pF @ 4V, 1MHz
|
|
Mounting Type
|
Surface Mount
|
Surface Mount
|
|
Package / Case
|
SOD-123F
|
DO-214AA, SMB
|
|
Operating Temperature - Junction
|
-65°C ~ 150°C
|
-65°C ~ 150°C
|
|
Base Product Number
|
FSM17
|
RS1M
|
If you have a need for FSM17PL-TP-HF, feel free to contact us, while we will inspect and provide test reports.
