| Name | Value |
|---|---|
| Product Status | Active |
| Type | Enclosed, Conformal Coated |
| Voltage - Input (Min) | 14.4V |
| Voltage - Input (Max) | 36V |
| Number of Outputs | 2 |
| Voltage - Output 1 | 5.1V |
| Voltage - Output 2 | 5.1V |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 15A, 15A |
| Power (Watts) | 97W |
| Voltage - Isolation | - |
| Applications | ITE (Commercial), Railway |
| Efficiency | 86% |
| Operating Temperature | -40°C ~ 71°C |
| Mounting Type | Chassis Mount |
| Size / Dimension | 6.73" L x 4.37" W x 0.78" H (171.0mm x 111.0mm x 19.8mm) |
| Approval Agency | CE, CSA, EN, IEC, TUV, UL |
| Standard Number | - |
