| Name | Value |
|---|---|
| Product Status | Active |
| Terminal Type | PC Pin |
| Terminal Style | Double End |
| Pin Size - Above Flange | 0.052" (1.32mm) Dia |
| Pin Size - Below Flange | - |
| Length - Above Flange | 0.115" (2.92mm) |
| Length - Below Flange | 0.312" (7.92mm) |
| Length - Overall | 0.458" (11.63mm) |
| Flange Diameter | 0.075" (1.91mm) |
| Mounting Hole Diameter | 0.059" (1.50mm) |
| Mounting Type | Through Hole |
| Termination | Swage |
| Insulation | Non-Insulated |
| Board Thickness | - |
| Contact Material | Brass |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
