| Name | Value |
|---|---|
| Product Status | Active |
| Tail Type | No Tail |
| Termination | Press-Fit |
| Length - Overall | - |
| Accepts Pin Diameter | 0.016" ~ 0.021" (0.41mm ~ 0.53mm) |
| Accepts Square Pin Size | 0.011" x 0.018" (0.28mm x 0.46mm) |
| Pin Hole Diameter | - |
| Mounting Hole Diameter | 0.045" (1.14mm) |
| Flange Diameter | - |
| Tail Diameter | - |
| Socket Depth | 0.095" (2.41mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Tin-Lead |
| Contact Finish Thickness | 80.0µin (2.03µm) |
