| Name | Value |
|---|---|
| Product Status | Active |
| Type | Plug, Female Sockets |
| Number of Positions | 8 |
| Positions Per Level | 8 |
| Number of Levels | 1 |
| Pitch | 0.138" (3.50mm) |
| Header Orientation | - |
| Plug Wire Entry | 90° and 270° |
| Termination Style | IDC |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | 6A |
| Voltage - IEC | 250 V |
| Current - UL | 7 A |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG | 20-22 AWG |
| Wire Gauge or Range - mm² | 0.35-0.5mm² |
| Color | Black |
| Operating Temperature | -50°C ~ 80°C |
| Contact Mating Finish | Tin |
| Features | - |
